Home > Products > Couplers/Hybrids > Waveguide Coupler > Dual Directional Waveguide Coupler > TDC-075110-10-10
TDC-075110-10-10
TDC-075110-10-10 is a four-port waveguide dual-directional coupler that delivers a 10 dB nominal coupling level and 30 dB minimum directivity across the full waveguide band from 75 to 110 GHz. The interfaces of the dual-directional coupler configuration offers an inline structure with WR-10 waveguides and UG-387/U-M anticocking flanges.
Frequency(GHz) Min75
Frequency(GHz) Max110
Coupling(dB)10
Isolation(dB)
Directivity(dB)30
VSWR1.1
RF ConnectorWR-10
Specification Click to download the specification
